Synq DMC.1000
Description
This professional digital media controller will even satisfy the most demanding DJs! You can play and scratch music from different sources, including CDs (audio+MP3) and MP3 from FAT32 USB-drives. With its MIDI features the DMC.1000 can control VirtualDJ.
Manufacturer's website: http://en.beglec.com/product/348/DMC-1000
Specification/features
- USB-link: Simultaneous playback from one USB-drive on 2 decks!
- Q-DBase system: Smart, fully featured database lookup system to find your tracks very easily, even on big hard disks!
- High precision scratch function and pitch bend, thanks to the touch-sensitive jog wheel.
- 2x 10 character alphanumeric VFD-display shows information, including ID3-tags & CD-text (CD & USB media only - Text display in MIDI mode may be supported in a future firmware update.)
- Pitch control (+/-6%, 10%, 16%, 100%) also on MP3.
- Pitch lock (Master Tempo)
- Fully customizable setup menu for MIDI and other functions.
- Reliable slot-in CD-mechanism.
- Headphones output with adjustable volume (CD & USB media only.)
- Relay play allows consecutive playback on two decks.
- Fader start/stop (back cue), compatible with most professional DJ mixers.
- S/PDIF digital audio RCA coaxial.
- Dimensions: 296 (D) x 218 (W) x 103.5 (H) mm
- Weight: 2.5kg
How to enable MIDI mode for use with VirtualDJ
- Windows 7 users will need to install the latest firmware: http://en.beglec.com/product/348/DMC-1000
- Connect each DMC.1000 to your computer.
- Hold down the ENTER button on the DMC.1000 for 3 seconds to enter its setup menu.
- Turn the FOLDER knob to choose B.MIDI Setup
- Turn the TRACK knob to choose USB = LINK (This should be selected already.)
- Turn the jogwheel to change it to USB = MIDI
- Turn the FOLDER knob to choose G.Exit&Save
- Press the TRACK knob to save.
How to put the DMC.1000 into MIDI mode
- Hold down the SOURCE button on each DMC.1000 for 3 seconds.
- Press the A button on the left player and B on the right player. If you only have one player, you can use these buttons to toggle between the two decks.
- Press SOURCE to exit MIDI mode.
NOTE: If you do this with VitualDJ running (E.g: To play a CD) and then go back to MIDI mode again, you will need to go to CONFIG -> Mappers, click on the button to the right of the drop-down list and choose Rescan for new devices.
